direct drive
The Asco solenoid valve series is a solenoid valve with a valve body made of brass and internal parts made of stainless steel. This is the best solution for non-aggressive liquids and gases.
The Asco solenoid valve is an electromagnetic device for allowing or preventing liquids (with a maximum viscosity of 35 mm²/s) or gases to pass through. The valve has internal openings from 1.1 to 45 mm and seals made of NBR, EPDM or FPM. This makes it suitable for operating pressures up to 30 bar, depending on the variant.
Asco solenoid valves
Asco Dry solenoid valves
Direct acting valve
2/2- or 3/2-way versions, NC or NO
Ports with gas thread from 1/8” to 2”
Internal openings from 1.1 to 45 mm
Material of valve body:
brass
Material of internal parts:
stainless steel
Elastomers:
NBR, EPDM or Viton® FPM
Operating pressures from vacuum to 30 bar
Coils in class F (155 ºC) or H (180 ºC)
Suitable for export
