plastic valves for aggressive fluids
The Asco Dry solenoid valve series is a plastic valve that is ideal for aggressive liquids and gases, thanks to the valve body made of technopolymer and the internal parts made of stainless steel.
The Asco Dry solenoid valve has a separation between the internal parts of the valve or coil and the medium. The coil controls the opening and closing movements by means of a lever (in an elastic protective sleeve) or a membrane (on the inside of the valve). Depending on the diameter, the response time can vary from a few tens of milliseconds for direct acting valves to a few hundreds or thousands of milliseconds for indirectly operated or membrane coupled valves.
Asco solenoid valves
Asco solenoid valves
Direct acting valve
Separation between internal parts and medium
2/2- or 3/2-way versions, NC or NO
Ports with gas thread from 1/8” to 2”
Internal openings from 1.5 to 43 mm
Material of valve body:
stainless steel or plastic
Material of internal parts:
stainless steel
Elastomers:
NBR, EPDM or Viton® FPM
Operating pressures from vacuum to 12 bar
Suitable for export
View product
direct drive
View product
